24″ Round Flat Pan Push Button HPC Fire Pit Insert PENTA24FPPK-FLEX Product Details
This is our mid-range fire pit insert utilizing safety pilot flame control- simply push the ignition button and valve control knob to start… flame adjustment is done with the knob. This battery-operated system is a good solution for flame sensing necessity without AC power requirements.
How It Works
Start-Up: This is done by simultaneously pressing the valve control knob to start the flow of pilot gas and pressing the ignition button for spark. Release spark after pilot ignition, release valve control knob after ~20 seconds. Then turn the valve control knob counterclockwise to light the main burner. Operation: Flame height may be adjusted by turning valve control knob- counterclockwise provides more flame, clockwise lowers flame. If flame loss does occur, the system will automatically turn off all gas flow. Shut Down: To turn OFF the fire pit simply turn the valve control knob clockwise- slightly depress knob to reach OFF position.
Purchase the HPC Fire 24″ Round Flat Pan Push Button Fire Pit Insert PENTA24FPPK-FLEX here in Flame Authority!
Features
Features:
- Fully Assembled and ready to install. Control components are protected within the valve box.
- Flex Line configuration provides versatile and simple installation.
- Start ignition with push button and valve control knob.
- Flame sensing- the system will turn off gas if the flame is lost.
- Flame height is adjustable using a valve control knob.
- Battery Operated System- This is the perfect solution for installs with no power.
- Liquid Propane: Factory built & tested.
- CSA Certified in US & Canada to ANSI Z21.97-2017 / CSA 2.41-2014 requirements.
